Grundfos - G100 - 1/2" sweat with check valve - 96806141

The Grundfos 96806141 G100 Connection Kit is a circulator-pump accessory featuring a 1/2-inch copper sweat connection and an integrated check-valve insert. The assembly provides a soldered connection between compatible copper piping and a Grundfos circulator while helping prevent unwanted reverse flow when the pump is not operating. As shown, the kit consists of a brass sweat tailpiece, threaded union nut, sealing gasket and check-valve component, allowing the circulator connection to be disconnected for service without cutting the adjoining copper pipe. It is intended for compatible Grundfos circulation and domestic hot-water recirculation installations requiring the G100 connection configuration.

Cross References

Grundfos — 96806141: Standard manufacturer part number

Grundfos — G100: Connection configuration or accessory designation used for this assembly

Distributor description: G100 – 1/2 in sweat with check valve

No verified alternate Grundfos MPN was located for this exact product.

Usage

The Grundfos 96806141 kit connects compatible circulator equipment to 1/2-inch copper tubing using a soldered sweat joint. Its internal check valve permits flow in the intended direction while limiting reverse circulation when the pump stops. The union-style connection allows the circulator to be removed for inspection or replacement while leaving the soldered tailpiece attached to the piping.
